Convex Wireless B&W Ultrasound 3.5- 5.0Mhz



Contact Us

Pocket Convex Ultrasound 3.5- 5.0Mhz B&W Scanner

  InterAktiv Scan sells Wireless Ultrasound,ultrasound scanner,Pocket Ultrasound,ultrasound machine,Portable Ultrasound,ultrasound devices for sale,Real Time Ultrasound,veterinary ultrasound price,veterinary ultrasound equipment,Handheld Ultrasound,vet ultrasound,Real Time Ultrasound,Handheld Ultrasound,real time ultrasound machine,ultrasound,scan probe,Buy Ultrasound Machine,doppler ultrasound buy,iphone ultrasound probe,Wireless Ultrasound,Realtime Ultrasound,diagnostic ultrasound for sale,Veterinary Ultrasound,Handheld Ultrasound,Portable Ultrasound,Real Time Ultrasound Machines,Realtime Ultrasound,Pocket Ultrasound, bladder scanners

The new series II SS-2 convex Wireless Scanner offers selectable frequencies between 3.5Mhz and 5.0Mhz.

How does it work: The probe connects via Wi-Fi to your chosen device, which can be iPhone, Ipad, Android phone or tablet or a PC running WIN10 operating system. The Ultrasound probe is discovered in the Wi-Fi setting page of your device and connects once selected. Open the software App and the unit is ready to scan, there are no on-going subscriptions or licence fees.

Functions:Many functions found on larger ultrasound system can be found on the Wireless US such as: adjusting gain, dynamic range, focus position, depth, colour mode & sensitivity. The linear probes offer steer function in colour mode. There is also a biopsy mode which applies an adjustable guiding line for needle angle guide. On screen measurements can be done using the caliper setting were anchoring or moving measurement cursors with your finger or a stylus.

Like all ultrasounds, you can record patient data and save individual images to your devices memory or photo library as well as cine loop video

Wireless US app to iPhone, iPad or smart phone for a convenient, compact, transportable Ultrasound that can be applied to many applications:

  • Pelvic Floor evaluation
  • Bladder scan
  • OB
  • Tranversus Abdominis
  • Lung
  • General Abdominal scans

Features:

  • Workable with Tablet or Smart Phone
  • Built-in and replaceable battery
  • Advanced digital imaging technology, clear image
  • High cost-effective
  • Wireless connectivity, easy to operate
  • Small and light , easy to carry
  • Applicable in emergency, clinic, outdoor and vet inspection
  • Intelligent terminal platform, powerful expansion functions on application, storage, communication, printing
Specification:

Display: iPad Series
Frequency: 3.5MHz/5MHz
Scanning Mode: Convex array available in two models: 128 element (SS-2)
Scan: Sector Scan 80 degre
Depth: adjustable >200mm
Gray Scale: 256 levels
Display Mode: B Mode, BM Mode

Measurements: Length, Area/Circumference, GA(CRL,BPD,GS,FL,HC,AC)

Footprint: 156mm×60mm×20mm
Weight: 308 gram
Battery last: 3 hours





Code: SS-2 ( 128 Element Convex)



ARTG: 278643
