MSU3 Digital Mechanical Sector Ultrasound

Cow, Sheep, Cat/Dog Pregnancy Test Machine Veterinary Imaging Doppler Ultrasound

The MSU3 is the perfect entry level ultrasound for abdominal scan pregnancy testing. Compact, lightweight design with 5"high-resolution colour LCD making the MSU3 portable and suitable for outdoor use.

Features:

• Pregnancy testing
• Backfat measurement
• Large capacity battery, 300min
• Compact and Lightweight, under 650g

Technical Specifications:

• Using the latest cortex-m4 embedded control system + miniaturized exclusive ultrasound technology hardware system; has a triple function of A scan, B scan, and ear tag scan, the perfect solution to the various needs of users;
• 5"high-resolution colour LCD, small size, lightweight and portable, suitable for outdoor use;
• Gray:256
• Display mode: B, 2B, A mode
• B mode and A mode gain range: 27 ~ 90dB
• Near field gain: -31 ~ 0dB;
• Far Field Gain: 0 ~ 31dB;
• Dynamic range:27~90dB
• 3 kinds of depth range, 126,163,200, the maximum display depth of 200mm;
• Compression curve adjustment: 4 kinds, from 0 to 3;
• Frequency: 2.5Mhz & 3.5MHz
• Frame correlation: 0 ~ 5,6 kinds;
• Pseudo-colour function: 0 ~ 7,8 species (including black and white);
• Able to measure backfat thickness, muscle thickness, and lean percentage;
• Image Storage: image or measurement data stored in the U disk;
• Scale of the image display: 3 kinds, "0" is not displayed ruler, "1" is displayed 10mm pitch of dot scale, "2" is displayed vertical and horizontal pitch of 10mm dot scale;
• Supports 3 kinds ear tag format: EM4305, EM4100, T5557;
• Unique ear tag scanning function: ear tag scanning within a set time (10-30 seconds) to complete the ear tag scanning;
• B scan and A scan measured data can be stored in an Excel table, user-friendly data management, processing all kinds of information;
• Unique menu display settings: Menu disappears automatically at a set time, user-friendly observation image;
• Screen saver function;
• System settings probe guard time, automatically freeze, protect probe;
• Dual power supply. Power: 100-240V ~ ± 10% 1.2-0.6A Frequency: 50-60Hz ± 1Hz;
• Large Battery capacity (2600mAh) lithium battery can support more than 300 minutes of work;
• Net Weight: 620g;
• Main unit size: 90×98×25mm (length x width x height)

 Standard Configuration:

• Main unit: 1 pc
• 5MHz mechanical sector probe: 1 pc
• Power adapter: 1 pc
• Internal battery : 1pc
• Power line: 1 pc
• Shutter release line: 1 pc
• Instrument backpack: 1 pc
• OTG U disk: 1 pc
